Main feature
•Good performance & good technical parameters.
•Modular structure, high reliable and easy to upgrade and maintain.
•With spontaneous heat dissipation.
•Local and remote monitoring function which access to the NMS.
•With a perfect protection function.
Schematic Diagram
.Power Supply and Mechanical Specification
|
Power Supply
|
AC: 90~270VAC
|
|
Dimension and Weight
|
600mm*500mm*234mm, ≤30kg
|
|
Max. Power Consumption
|
10W：≤380W
|
|
Operating Temperature
|
-5~+55℃
|
|
Operating Humidity
|
≤95%
|
|
Environmental Class
|
IP65
|
|
RF Connector
|
N-Female, 50ohm
|
|
MTBF
|
≥50000 hours
|
|
Monitor Interface
|
Local Monitor: RS232, Remote Monitor: GSM Modem
|
Electronic Specification
|
Technical specification
|
GSM900
|
GSM1800
|
||
|
Frequency range
|
uplink
|
890～915MHz
|
1710～1765MHz
|
|
|
downlink
|
935～960MHz
|
1805～1860MHz
|
||
|
Output power
|
uplink
|
20dBm±2dB
|
20dBm±2dB
|
|
|
downlink
|
30~43dBm±2dB
|
30~43dBm±2dB
|
||
|
Filter bandwidth
|
0.5～15 MHz（adjustable by software）
|
|||
|
Gain flatness
|
≤5dB（P－P）
|
|||
|
Selectivity（offset off filter frequency working band）
|
600 KHz
|
≤-30dBc
|
||
|
≥1MHz
|
≤-35dBc
|
|||
|
Max gain
|
uplink
|
80±3dB
|
80±3dB
|
|
|
downlink
|
85±3dB
|
85±3dB
|
||
|
Intermodulation attenuation
|
uplink
|
≤-45dBc@20dBm
|
≤-45dBc@20dBm
|
|
|
downlink
|
≤-45dBc@33dBm
|
≤-45dBc@33dBm
|
||
|
Gain manual control
|
31dB@1dB/step
|
|||
|
Gain auto level control
|
≥25dB
|
|||
|
Spurious
|
9KHz～1GHz
|
≤-36dBm
|
||
|
1GHz～12.7GHz
|
≤-30dBm
|
|||
|
Noise figure
|
≤6dB
|
|||
|
VSWR
|
≤1.5
|
|||
|
Propagation delay
|
≤10μs
|
|||
|
Port resistance
|
50Ω
|
|||
|
Power supply
|
AC165~285VAC，50Hz
|
|||
|
connector
|
N-F Type（F）
|
|||
|
Working temperature
|
-25℃～+50℃
|
|||
|
Relative humidity
|
≤95％
|
|||
|
Protection rank
|
IP20
|
|||
|
Interface
|
RS-232
|
|||
Notes: this is our normal specification on Dual band repeater, your special requirements can be customized at Sky PFM.
