Our thermal magnetic imager extract & process the magnetic signal, and overlay on the original thermal infrared signal, which come into being compound signal, in this way to improve the thermal magnetic imager on the capability of penetrate the fog and dust, and longer the detect distance and clarity and builds up layers of the object, compared to infrared imager, themal magnetic imager 30%~50% better and clear on the detect the objective distance, imaging definition,space hierarchy,high Luminous & strong penetrating fog, rain and dust.
Main function:night vision reconnaissance & fire rescue
Main feature:
◆thermal & magnetic compound signal detecting and overlay processing
◆un-cold and passive imaging
◆work upon power on, no need to wait initialization and preheat
◆penetrate the fog & dust Efficiently;
◆builds up layers of the object;
◆automatically non-uniformity correction & background makeup,
◆double overview signal output;
◆Light housing of aluminum milling & casting & LED Display screen;
Technical specification
imaging resolution: 320×240
viewing angle: 36°× 27°
lens: 19mm germanite glass
detector: high sensitivity, matrix, vanadium oxide, focal plane detection
video output: PAL
scanning frame rate: 25 frame/sec
detect wave:8.2~14.5um
space detect pixel size: 38um
Physical characteristics
external material: space aluminum
working power: Lithium battery 9V~12V(4000mA)
working temperature: -25℃~65℃
display: 2.5″ LED 720×576
detect distance: condition: atmosphere temperature 15℃~22℃、humidity 38%~40%,detect distance:200~300meter(adult)、500m~800m(Vehicle)
weight: 1.5Kg
host size: 138mm×110mm×85mm
hand shank size: 90mm×63mm×30mm
